RS485 fan coil thermostat, 2/4 pipe fan coil thermostat T15FCT

Weight:
0.25kg
Dimension:
84mm×121mm×28mm

Main Features

New vertical design, crosswise installation or vertical installation. Auto fan with adjustable 3-fan speed. External sensor, Remote control. 2 pipe or 4 pipe heating and cooling. Permanent user setting retention during power loss, no batteries are required. RS485 communication function.

Contact Now

Product Details

RS485 fan coil thermostat, 2/4 pipe fan coil thermostat T15FCT

FEATURE：

Large LCD display with backlight
2 pipe or 4 pipe heating/cooling available
Auto fan with adjustable 3-fan speed
7 days programmable
Permanent user setting retention during power loss, no batteries are required
Modbus communication

SPECIFICATION:

Power Supply: 100-240VAC 50/60Hz

Fan Relay Amps inductive: 8(5)A

Heat/Cool Relay Amps inductive: 1(0.5)A

Room Temperature Setting Range: 5°C to 35°C
