RS485 modulating thermostat T15PIT

Weight:
0.25kg
Dimension:
84mm×121mm×28mm

Main Features

New vertical design, crosswise installation or vertical installation. Auto fan with adjustable 3-fan speed. External sensor, Remote control. Permanent user setting retention during power loss, no batteries are required. 2 pipe or 4 pipe heating and cooling. RS485 communication function.

Contact Now

Product Details

RS485 modulating thermostat T15PIT

FEATURE：

New vertical design, crosswise installation or vertical installation.
Auto fan with adjustable 3-fan speed.
External sensor, Remote control.
Permanent user setting retention during power loss, no batteries are required.
2 pipe or 4 pipe heating and cooling.
RS485 communication function.

SPECIFICATION:

Power Supply: 100-240VAC 50/60Hz

Fan Relay Amps inductive: 8(5)A

Heat/Cool Relay Amps inductive: 0.5°C

Accuracy: ±0.5°C

Set point Temperature Range: 5°C to 60°C
