Weather-based smart irrigation controllers
Weather-based controllers, also referred to as evapotranspiration (ET) controllers, use local weather data to adjust irrigation schedules. Evapotranspiration is the combination of evaporation from the soil surface and transpiration by plant materials. These controllers gather local weather information and make irrigation run-time adjustments so the landscape receives the appropriate amount of water.
ET weather data uses four weather parameters: temperature, wind, solar radiation and humidity. It’s the most accurate way to calculate landscape water needs.
There are three basic forms of these weather-based ET controllers:
• Signal-based controllers use meteorological data from a publicly available source and the ET value is calculated for a grass surface at the site. The ET data is then sent to the controller by a wireless connection.
• Historic ET controllers use a pre-programmed water use curve, based on historic water use in different regions. The curve can be adjusted for temperature and solar radiation.
• On-site weather measurement controllers use weather data collected on-site to calculate continuous ET measurements and water accordingly.
Soil moisture sensors used with smart irrigation controllers
Soil moisture sensor-based smart irrigation controllers use one of several well-established technologies to measure soil moisture content. When buried in the root zone of turf, trees or shrubs, the sensors accurately determine the moisture level in the soil and transmit this reading to the controller.
There are two different soil moisture sensor-based systems available:
• Suspended cycle irrigation systems, which are set like traditional timer controllers, with watering schedules, start times and duration. The difference is that the system will stop the next scheduled irrigation when there is enough moisture in the soil.
• Water on demand irrigation requires no programming of irrigation duration (only start times and days of the week to water). It has a user-set lower and upper threshold, which initiates irrigation when the soil moisture level fails to meet those levels.
