 /modulating room thermostat SAS920PIT
Outdoor ControllerOutdoor Controller

modulating room thermostat
modulating room thermostat modulating room thermostat modulating room thermostat

modulating room thermostat SAS920PIT

  • Weight:

    0.25kg

  • Dimension:

    86x86x12mm
Main Features
Large LCD display with backlight.  Temperature adjustments are simple with the large up-down arrows.  Display shows both set points and room temperature simultaneously.  Maintains the temperature to within 1 degree set point.  Auto fan with adjustable 3-fan speed..  Permanent user setting retention during power loss, no batteries are required.  0 to 10VDC or 4 to 20mA cool outp.
Contact Now
Product Details

modulating room thermostat  SAS920PIT


FEATURE：

Large LCD display with backlight.
Temperature adjustments are simple with the large up-down arrows.
Display shows both set points and room temperature simultaneously.
Maintains the temperature to within 1 degree set point.
Auto fan with adjustable 3-fan speed..
Permanent user setting retention during power loss, no batteries are required.
0 to 10VDC or 4 to 20mA cool outp.


SPECIFICATION:

Power Supply: 18-30VAC 50/60Hz
Fan Relay Amps inductive: 8(5)A
Modulating output Voltage: 4 to 20mA or 0 to 10VDC
Room Temperature Setting Range: 5°C to 35°C



Tags : best modulating thermostat modulating smart thermostat smart modulating thermostat modulating thermostat 0-10v modulating thermostat
