/Water heating thermostat SAS923WHL-7

Water heating thermostat SAS923WHL-7

  • Weight:

    0.25kg
  • Dimension:

    86x86x12mm
Main Features
SAS923WHL-7 is a programmable thermostat designed for floor warming application or helping to limit floor temperature. This thermostat can be used for hot water radiant heating systems and electric heating cable system.
Product Details

Water heating thermostat SAS923WHL-7

SAS923WHL-7 is a programmable thermostats designed for floor warming application or helping to limit floor temperature. This thermostat can be used for hot water radiant heating systems and electric heating cable system.


Feature:

1. 4 inch large screen display

2. Control water valve, electric heat actuator, water pump, wall hanging furnace

3. Permanent user setting retention during power loss

4. Display temperature correction

5. Optional types of control for different heating application including room thermostat; floor thermostat or roomthermostat with floor limitation

6. Optional programming Period: 7 individual day programming

7. Touch button

7-day programm water heating thermostat

Power source

100-240VAC50/60Hz

Maximum load electric current

3A/250VAC

Room temperature setting range

5℃- 35℃

External sensor control range

5 ℃-70 ℃ (not standard)

Accuracy

0.1℃

Working environment temperature

0℃- 50℃

The storage temperature

-10℃- 60℃

Dimensions

86mm X 86mm X 13mm




Water heating thermostat
