DX THERMOSTAT SAS908MTW

SAS908MTW

Get a quote

Large LCD display with backlight

Set points and room temperature display simultaneously

Adjustable 3-speed fan with fan stop option

The screen displays the set temperature, the room temperature simultaneously

Never lose user setting in the event of power-off, no battery is required

Display temperature recalibrates

Inner Sensor or External sensor option

Home Product Commercial Thermostats DX Unit Thermostats

Product Description

DX Unit Thermostat With Large Backlit Display support for Modbus RTU communication, and 3-speed fan control, 2H/2C and 1H/1C options.

Product Selector

Model No.

Heat/cool

Cool only

Pipe

Speed fan

Programmable

Window card

Room card

External Sensor

Modbus RTU

WIFI

Power

Manual

SAS908MTW-0-S-485

√

220/24VAC

download

SAS908STW-0-S

1H/1C

√

24VAC

download

SAS908MTW-0-S

2H/2C

√

24VAC

download

SAS908STW-0-F1

√

220VAC

download

Product Parameters

Power Supply: 18-30VAC or 100-240VAC 50/60Hz
Fan Relay Amps inductive: 5(3)A
Heat Relay Amps inductive: 1(0.5)A
Room temperature setting range: 5°C to 35°C (41°F to 95°F)
Modulating output voltage: 0 to 20mA or 0 to 10VDC
Accuracy:±0.2°F or ±0.1°C
Dimensions: 115mm×90mm×35.5mm
