BACnet THERMOSTAT

T29MTW-7-S-BACnet

BACnet THERMOSTAT

Get a quote

Big screen and touch key for easy operation

Color display

Wall mount to easy hanging on wall

Compatible for fan coil and DX unit

BACnet communication

Up to 2 stage heating and cooling

Home Product Commercial Thermostats DX Unit Thermostats

Product Description

Application: Compatible for fan coil and DX unit，BACnet communication，Up to 2 stage heating and cooling

Product Selector

Model No.

Heat/cool

Cool only

Pipe

Speed fan

Programmable

Window card

Room card

External Sensor

BACnet RTU

WIFI

Power

Manual

T29MTW-7-S-BACnet

√

2/4

1/3

√

220/24VAC

download

Product Parameters

Power Supply: 100-240VAC 50/60Hz；24(18~30) VAC 50/60Hz
Realy for fan: 8(5)A
Standby current: <1W
Heat/Cool Relay Amps inductive: 3(2)A
Temperature setting range: 0°C to 50°C
Accuracy: 0.1°C
Storage temperature: -10°C to 60°C
Operation temperature: 0°C to 50°C
Dimensions: 135mm×92mm×27.5mm

FAQ

You could choose the types you like, and then sent the model no. to the email box info@saswell.com. Our salesman will get in touch with you within 24 hours. And we will send the data sheet to you for double check. Then we will prepare the sample accordingly. The sample needs to charge. So we will calculate the fare by emails back the proforma invoice for your reference. Then we will express the sample to you by express, you could get the sample about 4-5 days later.
