/Modulating Fan Coil Unit SAS922PIT-CO-F3-485

Modulating Fan Coil Unit SAS922PIT-CO-F3-485

  • Weight:

    0.25kg
  • Dimension:

    86x86x12mm
Main Features
Modulating Fan Coil Unit SAS922PIT-CO-F3-485 are designed to provide Proportional-Integral (PI) modulating control in 2-pipe fan coil units. This thermostat can provide modulating analog 0-10V or 0-20mA control signal.
Product Details

Fan coil thermostat SAS922FCT-EC-485

Modulating Fan Coil Unit SAS922PIT-CO-F3-485 are designed to provide Proportional-Integral (PI) modulating control in 2-pipe fan coil units. This thermostat can provide modulating analog 0-10V or 0-20mA control signal.

Feature:

1. Touch button easy for operation

2. 7 days programmable

3. Heating,cooling and ventilation mode

4. Auto fan with adjustable 3-fan speed

5. Permanent user setting retention during power loss, no batteries are required

6. Room Sensor or External sensor model option

7. Display shows both set points and room temperature simultaneously

8. Modbus communication

9. For fan coll unit or modulating (4 to 20mA or 0 to 10VDC) system




Electrical Rating

100-240VAC 50/60HZ

Fan Relay Amps inductive

8(5)A

Heat/Cool Relay Amps inductive

3(2)A

Room Temperature Setting Range

5℃-35℃
