Water Floor Heating Thermostat manufacturer,China Water Floor Heating Thermostat

SAS816WHL-0

Mechanical knob thermostat

Get a quote

Designed for ease of use, ideal for all age groups

Durable materials ensure long-lasting performance

Easy setup reduces installation time and costs

Simple design reduces the likelihood of technical issues

Minimized electronics for lower energy consumption

Intuitive dial operation with fast, precise response

Home Product Residential Thermostats Hydronic Thermostats

Product Feature

SAS816WHL-0 is a non-programmable thermostat designed for water floor heating systems. The thermostat can be controlled by build-in sensor or remote sensor.It is linked control, passive output to control boiler heating and valve actuator.

Product Selector

Model No.

Heat only

Cool only

Wired

Wireless

Programmable

Relay

Link with boiler

External Sensor

WIFI

Power

Manual

SAS816WHL-0

√

220V

download

Product Parameters

Power source: 100~240VAC 50/60HZ

Resistant Load current: 250VAC 5A

Inductive Load current: 250VAC 3A

Room temperature setting range: 5℃~30℃ (41℉~90℉)

Floor temperature setting range: 5℃~ 40℃(41℉~99℉)

Accuracy: ±1℃ or ±1℉

Dimensions: 86mm×86mm×32mm

Color: White

FAQ

You could choose the types you like, and then sent the model no. to the email box info@saswell.com. Our salesman will get in touch with you within 24 hours. And we will send the data sheet to you for double check. Then we will prepare the sample accordingly. The sample needs to charge. So we will calculate the fare by emails back the proforma invoice for your reference. Then we will express the sample to you by express, you could get the sample about 4-5 days later.
